Xtend Saga EMS – Encapsulator Modulator System

The Forsway-branded Xtend Saga EMS product is a high-performance DVB-S2 Modulator and IP Encapsulator featuring ACM (adaptive coding and modulation) and MPE (Multiprotocol Encapsulation) support, fully integrated with the Forsway Xtend complete satellite extension ecosystem.

The Xtend Saga EMS modulators and encapsulators provide efficient transmission of satellite data. Xtend Saga EMS ensures adaptation of IP data provided by the Forsway Mímir Gateway for transmission-over-satellite and is a key component of the Forsway Xtend Hub. The Forsway EMS system currently supports DVB-S2/ACM with MPE encapsulation, while hardware provided by the EMS also supports these features.

Key benefits

  • Significantly simplified workflow

  • Pre-integrated with Forsway Mimir NMS, enabling operators to seamlessly control operations from one portal

  • Provides benefits on performance, pricing, and robustness

Saga EMS ensures optimal efficiency in the transmission of satellite data

IP Encapsulator

  • Multiprotocol Encapsulation (MPE).

  • EBIS support – Generate the MPE MAC address using two fixed octets and the IP address.

  • OpenTMP protocol for ACM messages.

  • Maximum throughput performance – 247 Mbit/s
SAGA EMS DATA SHEET

Modulator

  • Supported standards: DVB-S2/ACM (including partial DVB-S2X support)

  • Output frequency: 32-2186 MHz
  • Bandwidth: Up to 72 MHz
  • Symbol Rate: 0.088 – 68.5 MSym/s
  • Constellations: QPSK, 8PSK, 16APSK
  • Coding: 1/2, 1/3, 1/4, 2/3, 2/5, 3/4, 3/5, 4/5, 5/6, 6/7, 7/8, 8/9, 9/10
  • FEC-frame: Normal/Short
  • Pilots: On/Off
  • Roll-off: 5%-35%

  • Output Level: -60 – 0 dBm

  • Output Connector: SMA 50 ohm
